| No. | Item | Unit | Data | ||
| Backhoe | Face shovel | ||||
| 1 | Machine weight | t | 48 | 50 | |
| 2 | Electromotor | Rated power | kW | 250 | |
| Rated voltage | V | 6000 | |||
| Rated speed | r/min | 1480 | |||
| 3 | Hydraulic system | System pressure | MPa | 32 | |
| Max. flow | L/min | 2×401 | |||
| 4 | Swing device | Swing speed | r/min | 8.3 | |
| Tail swing radius | mm | 3874 | |||
| 5 | Pilot system | System pressure | MPa | 4 | |
| System flow | L/min | 21.5 | |||
| 6 | Traveling device | Traveling speed | km/h | 3.62 | |
| Ground pressure | MPa | 0.0987(560mm track pad) | |||
| Pulling force of the | kN | 2×353.32 | |||
| 7 | Working parameters | Boom specification | mm | 7060 | 4100 |
|
|
Stick specification | mm | 3380 | 2700 | |
|
|
Bucket capacity of backhoe | m3 | 2.1 | 2.5 | |
|
|
Max. digging reach | mm | 12018 | 8550 | |
|
|
Max. digging depth | mm | 7760 | 2270 | |
|
|
Max. digging height | mm | 10965 | 9920 | |
|
|
Max. dumping height | mm | 7655 | 7370 | |
|
|
Max. digging force of stick | kN | 217 | 269 | |
|
|
Max. digging force of bucket | kN | 236 | 271 | |
This mini excavator has the advantages of flexible and practical, high configuration, high performance, low oil consumption, beautiful appearance and wide application.Suitable for vegetable greenhouses loose, landscaping of municipal departments, orchard nursery tree digging, concrete pavement broken, sand and stone material mixing and small space construction operations,reducing maintenance and operating costs, improving the degree of mechanization.
TYSIM PILING EQUIPMENT CO., LTD is the sole professional national high-tech enterprise of R&D and manufacturing small and middle piling equipment in China, with ISO9001 quality management system. The products include hydraulic piling rig, modular piling rig, hydraulic pile breaker, mechanical diaphragm wall grab and other related products. TYSIM KR series of small piling rigs and KP series of hydraulic pile breakers are the domestic famous brands.
